WS12 LED Wall Cylinder Light 120V-277V(20W)

WS12 LED Wall Cylinder Light 120V-277V(20W)

SKU: WM37-1-1 Category:

WS12 LED Wall Cylinder Light 120V-277V(20W)



       ◆   Die-cast aluminum housing for durability and heat dissipation.

       ◆   Adjustable color temperature and wattage for versatility.

       ◆   Three directional switch (Up/Down/Both).

       ◆   Long lifespan of 50,000 hours at 40°C.



  • INFORMATION

    The WM12 offers classical Look combining with advanced LED technology to bring you a slim-profile luminaries with uncompromising performance. With a built in Dusk to Dawn photo control for ultimate energy saving capability. This Fixture offers the perfect for illuminating application for residential, commercial, apartments and hotel building space.

  • SPECIFICATION

    ITEM WATTAGE      Wattage
    (Selectable)    		                CCT
    (Selectable)    		 Lumens Efficacy
    (lm/W)    		       Beam
    Angle    		 Photocell      Directional
    Switch    		       Surge
    Protection    		    Input
    Voltage    		 THD Operating
    Temp.    		 Power Factor Mounting
    WS12      20W 50%,75%,100%        3K/4K/5K (Y)    3027      151  70゜/106゜          Y Y(Up/Down/Both)         4KV    120-       277V <20%  -40~40°C    >0.9       Wall
    WS12-5CCT     35W 50%,75%,100% 2.7K/3K/3.5K/4K/5K (Y)    4500      128        102゜          Y Y(Up/Down/Both)         4KV    120-       277V <20%  -40~40°C    >0.9       Wall
    WS12-P-LB E26 socket base Max (2) 150W incandescent (2) Type A self-ballasted LED Max 11W

    Application
    ● Commercial Areas      ● Entrances & Doorways      ● Building Exteriors and Facades

    ● Restaurants                    ● Storefronts
