LED Wall Light Fixtures - LED Wall Pack 104W 120V-277V(WP52)

LED Wall Pack 104W 120V-277V(WP52)

SKU: WP52 Category:

LED Wall Pack 104W 120V-277V(WP52)




Model No: WP52

Control Option:Button Photocell optional

Power Factor (PF):>0.9 Total Harmonic Distortion (THD):<20%

Ambient Operating Temp. range:-30°C~30°C

Surge Protection:4KV(6KV/10KV avilable)

Lumen efficacy:Up to 135lm/w

Body construction:Die-cast Aluminum

Lens construction:Tempered Glass Lens

Mounting Option:1/2″NPS sides/knockouts


    The WP52 provides traditional architectural style with high performance energy efficient illumination. Listed as DLC Premium product back up it have superior quality and make it more attractive choice for contractors when select lighting products for their job. It is ideal for pathway illumination, building entrances, vehicle ramps, schools, tunnels, stairways and loading docks.


    Model No. Watts Lumens Color Input Voltage CRI Equivalent
    WP52 30 4006 4000K


    120V-277V 70 70W HID
    45 6217 100W HID
    67 9152 120V-277V


    150W HID
    104 14059 4000K


    250W HID


    WP52 Catalogue

--> -->
